Table 8. technical data venting, Continued) – State SBN85 390NE(A User Manual
Page 19
19
model sBn100250ne/a
input: 250,000 Btu/hr
total Vent height (feet)
Vent Connector size: 6 inches
6 8 10 15 20 30 50 100
input Btuh/hr rise
Vent Connector diameter (inches)
250,000
1 Ft
8
8
7
7
7
6
6
6
250,000
2 Ft
7
7
7
7
6
6
6
6
250,000
3 Ft
7
7
7
7
6
6
6
6
number
Combined input
of heaters
in thousands of Btu/hr
manifold and Common Vent diameter (inches)
2
500,000
9
9
9
8
8
7
7
7
3
750,000
12
12
10
10
10
9
8
8
4
1,000,000
14
14
12
12
10
10
9
9
model sBn100275ne/a
input: 275,000 Btu/hr
total Vent height (feet)
Vent Connector size: 6 inches
6 8 10 15 20 30 50 100
input Btu/hr
rise
Vent Connector diameter (inches)
275,000
1 Ft
8
8
7
7
6
6
6
6
275,000
2 Ft.
8
8
7
7
6
6
6
6
275,000
3 Ft
7
7
7
7
6
6
6
6
number of
Combined input
heaters
in thousands of Btu/hr
manifold and Common Vent diameter (inches)
2
550,000
10
9
9
8
8
8
7
7
3
825,000
12
12
12
10
9
9
8
8
4
1,100,000
14
14
14
12
12
10
9
9
model sBn85310ne/a
input: 310,000 Btu/hr
t otal Vent height (feet)
Vent Connector size: 6 inches
6 8 10 15 20 30 50 100
input Btu/hr
rise
Vent Connector diameter (inches)
310,000
1 Ft.
9
8
8
8
7
7
6
6
310,000
2 Ft.
8
8
8
7
7
7
6
6
310,000
3 Ft.
8
8
8
7
7
7
6
6
number of
Combined input
heaters
in thousands of Btu/hr
manifold & Common Vent diameter
2
620,000
10
10
9
9
8
8
7
7
3
930,000
14
12
12
12
10
9
9
8
4
1,240,000
14
14
14
12
12
12
10
9
model sBn85366ne/a, sBn85390ne/a
input: 366,000, 390,000 Btu/hr
total Vent height (feet)
Vent Connector size: 6 inches
6 8 10 15 20 30 50 100
input Btu/hr
rise
Vent Connector diameter (inches)
366,000
1 Ft
9
9
9
8
8
8
8
8
390,000
1 Ft
10
9
9
9
8
8
8
8
366,000
2 Ft
9
9
8
8
8
8
8
8
390,000
2 Ft
9
9
9
8
8
8
8
8
366,000
3 Ft
9
8
8
8
8
8
8
8
390,000
3 Ft
9
9
8
8
8
8
8
8
number of
Combined input
heaters
in thousands of Btu/hr
manifold & Common Vent diameter (inches)
2
732,000
12
10
10
9
9
9
8
8
780,000
12
12
10
10
9
9
8
8
3
1,098,000
14
14
14
12
12
10
9
9
1,170,000
14
14
14
12
12
10
10
9
4
1,464,000
16
16
14
14
14
12
12
10
1,560,000
16
16
16
14
14
12
12
10
taBle 8. teChniCal data Venting
(Continued)
