FEATURES
A-Control Panel
A1-Vibration adjustment
A2-Bass Volume Adjustment
A3-Volume Adjustment
A4-Audio Input Jack
A5-Audio Output Jack for linking multiple chairs
A6-Wireless Band Switch
A7-Power On/Off Switch
A8-12V DC Power Input Jack
A9-Power Indicator Light
A10-MP3 Input Jack
A11-Headphone Jack
A12-DC 3V/200mA Power Input Jack of TX
A13-Audio Input Jack of TX
A14-Power On/Off Switch of TX
A15-Wireless Band Switch of TX
A10
A2
A3
A4 A5
A6
A7 A8
A11
A9
A14
A13
A12
A15
AUDIO IN
OFF/ON
BAND
123……
……
DC
IN
DC
3V
A1
B-Accessories Supplied
B1-3m RCA Stereo to RCA stereo plug cable(1 PC)
B2-1m 3.5mm stereo male to 3.5mm stereo male cable (1PC)
B3-RCA female to female barrel adapter (2 PCS )
B4-0.15m RCA stereo male to 3.5mm stereo male cable (1PC)
B5-0.15m 3.5mm stereo male to 3.5mm stereo male cable (1PC)
B6-INPUT:100-240V AC 50/60Hz
OUTPUT:12V DC 1500mA 18W Main POWER Adapter.
B7-TX Box
C-Audio Specifications
.
Ⅰ
＞
＞
＜
＜
The unit specifications:
1)
2)
3)
4)
Signal-to-Noise Ratio(Amplifier):
Subwoofer:
50dB
Satellite:
60dB
Frequency Response: 60Hz~15kHz
Distortion:
Subwoofer:
4% (F=100Hz)
Satellite:
1% (F=1kHz)
Input: DC 12V/1.5A
Ⅱ
℃
℃
＜
.TX / RX specification:
1) TX Power supply 3V DC
2XAAA Batteries (BATTERIES ARE NOT INCLUDED )
2) TX Current: 40mA
3) RX Current: 20mA
4) TX Transmission distance: < 65.6 ft / 20 meters
(No buildings or other barriers)
5) Environmental temperature:
14 F~158 F / -10
~70
6) Modulation mode: FSK
7) TX Work frequency: 863.3, 863.9,864.55MHz
8) RX Work frequency: 863.3, 863.9,864.55MHz
9) TX Power:
10dBM
10) RX Sensitivity:-100dBM
11) RX frequency range: 50Hz~13KHz
12) Second harmonic suppression: -40dB
13) Band quantity: 3 channels
/200mA
0
0
DC-12V/1.5A
0.492ft/0.15m
B4
B7
*SOME PARTS MAY VARY SLIGHTLY
9.84ft/3m
3 28ft/1m
.
B2
B1
0.492ft/0.15m
B5
B6
B3
