Page 3
3
9.84ft/3m
0.328ft/0.1m
0.328ft/0.1m
B6
B7
B5
0.328ft/0.1m
*SOME PARTS MAY VARY SLIGHTLY
B-Accessories Supplied
B1-3m RCA Stereo male to 3.5mm stereo
cable (1 PC)
B2-INPUT:
OUTPUT:9V DC 1000mA 9W Main POWER Adapter.
B3-RCA female to female barrel adapter (2 PCS)
B4-0.1
RCA s
to
B5-TX Box
B6-0.1m
B7-3.5mm stereo
to
(1PC)
male
(EFFICIENCY LEVEL:
115V )
m
tereo female
3.5mm stereo male cable (1PC)
RCA stereo male to 3.5mm stereo male cable (1PC)
male
male cable
100-240V/50/60Hz
C-Audio Specification
Signal-to-Noise Ratio(Amplifier):Subwoofer:
50dB
Satellite:
60dB
Frequency Response: 60Hz~15kHz
Distortion: Subwoofer:
4% (F=100Hz)
Satellite:
1% (F=1kHz)
Input: DC 9V/1A
.
1) TX Power supply 3V DC
2) TX Current: 40mA
3) RX Current: 20mA
4) TX Transmission distance: < 65.6 ft / 20 meters (No buildings
or other barriers)
5) Environmental temperature: 14 F~158
/ -10
~70
6) Modulation mode: FSK
7) TX Work frequency: 914, 914.5,915MHz
8) RX Work frequency: 914, 914.5,915MHz
9) TX Power:
10dBM
10) RX Sensitivity:-100dBM
11) RX frequency range: 50Hz~13KHz
12) Second harmonic suppression: -40dB
13) Band quantity: 3 channels
Ⅰ
＞
＞
＜
＜
Ⅱ
＜
.The unit specifications:
TX / RX specification:
2XAAA Batteries (BATTERIES ARE NOT INCLUDED )
F
0
0
℃
℃
Need Help? Email: [email protected] Web:
Phone: 866.969.2603
www.thexrocker.com
IV
