2.7 Drill Arm Mounting & Access Holes; Route Fixture Harness
Note: If mounting two arm mounts, connect both using the same
bolts.
Arm Mounting Hole.
Drill thru 2x @.75”Dia.
Access hole
for Luminaire
harness. Drill
thru one side
@ 1.25” Dia.
