Pure Legato 2 - Manual (Page 5)

3
1. Switches between on and standby
2. Switch between modes ( DAB/FM/CD/SD/AUX 1/AUX 2/AUX 3)
3. Receives signal from remote control
4. Push to access EPG in DAB.
5. Enters ReVu for DAB pause and rewind
6. Record DAB to SD card
7. Slot for audio and MP3 CDs
8. Light shows when recording or accessing SD card via USB.
9. Slot for SD card.
10. SD and CD lights.
11. Changes the information shown on the display.
12. 3.5mm stereo input from iPod/Minidisc etc.
13. 3.5mm headphone socket (mutes speakers)
14. Eject/load CD.
15. Access alarms/timers, Intellitext and setup options.
16. Turn for volume.
Push and turn to browse and push again to select stations, tracks and menu options
17. Six shortcut buttons provide quick access to radio presets, CD/MP3 controls and menu
options
18. Configurable dual phono output giving fixed volume output for connection to an external
amplifier or recorder, or variable for connection to a powered subwoofer.
19. F-type connector for DAB/FM aerial. Unscrew plastic cap and remove to access.
20. Connect to a PC for software updates or to access an SD card.
21. S/PDIF optical digital out (DAB/FM/CD/SD). Remove plug to use.
22. 2 x Dual phono stereo inputs from iPod/Minidisc etc.
23. Spring loaded speaker connectors
Connect red socket to red on speaker and black socket to black on speaker
24. Power cord socket.
25. Mutes speakers/headphones.
26. Volume control.
27. CD/SD controls, also used for FM tuning and ReVu. and change day in DAB EPG.
28. Select and select stations/tracks and menu options.
Press Select to access DAB EPG and use arrows to navigate
29. Press Save + number or hold down number to store a preset. Press number to recall.
Press -/-- first for double digit presets.
Press to quickly access CD tracks
30. UK power plug adapter removal.
