8823
Parallel Arm
• Closer installed on push side of door.
• Standard mounting position permits door
opening to 120° (180° size 2).
Part Numbers
8823 Non hold-open
Over-Door Mounting
• Closer installed on push side of door, and
top rail where conditions do not allow
parallel mounting.
• Standard mounting position permits door
opening to 120° (180° size 2).
Part Numbers
8823 Non hold-open
210mm
38mm
40
210mm
38mm
40
Note: Actual unit supplied without cover
Note: Actual unit supplied without cover
