4/8/16Channel DVR Quick Manual
17
LAN: If the computer and DVR are in the same LAN, choose “LAN” mode .In this mode, the
image video transmission format is CIF and the frame rate is 25fps.
Internet: If the computer and DVR are in different LAN, choose “Internet”. In this mode, the
image video transmission format is CIF and the frame rate is 6fps.
Language: Chinese and English are optional.
Login: Click to login into DVR internet
Reset: Re-enter the above information
After login, the following real-time preview screen will display. Users can preview at the IE
end and perform the functions of video playback, video setup, alarming setup, etc. Please
refer to the manual in the CD for detailed operation.
2.13 Central Management Software (CMS)
This system supports connection to DVR through Internet, not through the support of
intermediate server. It is convenient for user’s management.
Software installation: Double click to run CD file “DVRCMS.msi”
，
finish as prompted. After
successful installation, double click desktop icon and run software. Display as the
following picture:
【
user name
】
: Create the initial user name for
login
【
password
】
: Create the initial password
【
Re-enter
】
: Confirm the initial password
【
Language
】
: Chinese and English are optional.
