PARTS LIST
ITEM
DESCRIPTION
PART #
1
1/4 - 20 X 2 3/4" Bolt - 1/2
– 3/4" Plastic Valves
5/16 - 18 X 1 1/2
” Bolt - 1” Metal Valves
1/4 - 20 X 5
” Bolt - 1” Plastic Valves (4.5” & 5” OD)
1/4 - 20 X 1 1/4" Bolt - 1/2 - 1" Metal Valves
PV-00101
PV-00102
PV-00105
PV-00108
2
1/4 - 20 Cap hex nut
PV-00202
3
1/4 Flat Washer (Required with 316 SS Top 1/2"
– 3/4")
5/16 Flat washer (Required with 316 SS Top 1
”)
PV-00302
PV-00303
4
1/2"
– 3/4" Valve Top – Noryl. Black
1/2"
– 3/4" Valve Top – Noryl, Orange
1/2"
– 3/4" Valve Top – Noryl, Yellow
1/2"
– 3/4" Valve Top – Noryl, Green
1/2"
– 3/4" Valve Top - 316 SS
1
” Valve Top – PVC, Black (For 4.5” OBS Body)
1
” Valve Top – Noryl, Black (for Plastic 5” Body)
1
” Valve Top – Noryl, Black (for Metal 5” Body)
PV-004451
PV-004452
PV-004053
PV-004054
PV-00407
PV-00411
PV-004175
PV-004171
BPV #
PRV #
5
1/2" Valve Body High Flow, PVC
1/2" Valve Body High Flow, PP
1/2" Valve Body High Flow, PTFE
1/2" Valve Body High Flow, PVDF
1/2" Valve Body High Flow, 316 SS
1/2" Valve Body High Flow, Alloy 20
1/2" Valve Body High Flow, Hast C
1/2" Valve Body High Flow, CPVC
3/4" Valve Body High Flow, PVC
3/4" Valve Body High Flow, PP
3/4" Valve Body High Flow, PTFE
3/4" Valve Body High Flow, PVDF
3/4" Valve Body High Flow, 316 SS
3/4" Valve Body High Flow, Alloy 20
3/4" Valve Body High Flow, Hast C
3/4" Valve Body High Flow, CPVC
1" Valve Body High Flow, PVC (4.5
” OBS)
1" Valve Body High Flow, PP(4.5
” OBS)
1" Valve Body High Flow, PTFE(4.5
” OBS)
1" Valve Body High Flow, PVDF(4.5
” OBS)
1" Valve Body High Flow, 316 SS(4.5
” OBS)
1" Valve Body High Flow, Alloy 20 (4.5
” OBD)
1" Valve Body High Flow, Hast C(4.55
” OBS)
1" Valve Body High Flow, CPVC(4.55
” OBS)
1" Valve Body High Flow, PVC (5
” OD)
1" Valve Body High Flow, PP(5
” OD)
1" Valve Body High Flow, PTFE(5
” OD)
1" Valve Body High Flow, PVDF(5
” OD)
1" Valve Body High Flow, 316 SS(5
” OD)
1" Valve Body High Flow, Alloy 20 (5
” OD)
1" Valve Body High Flow, Hast C(5
” OD)
1" Valve Body High Flow, CPVC(5
” OD)
BPV-00511HF
BPV-00512HF
BPV-00513HF
BPV-00514HF
BPV-00515HF
BPV-00516HF
BPV-00517HF
BPV-00518HF
BPV-00521HF
BPV-00522HF
BPV-00523HF
BPV-00524HF
BPV-00525HF
BPV-00526HF
BPV-00527HF
BPV-00528HF
BPV00531HF
BPV00532HF
BPV00533HF
BPV00534HF
BPV00535HF
BPV00536HF
BPV00537HF
BPV00538HF
BPV-50531HF
BPV-50532HF
BPV-50533HF
BPV-50534HF
BPV-50535HF
BPV-50536HF
BPV-50537HF
BPV-50538HF
TWO PORT CONFIGURED
HIGH FLOW
VALVE
USES BPV BODY
6
Pressure Spring - 1/2"
– 3/4" Valve; 150 psi
Pressure Spring - 1/2"
– 3/4" Valve; 50 psi
Pressure Spring - 1/2"
– 3/4" Valve; 250 psi
Pressure Spring - 1/2"
– 3/4" Valve; 350 psi
Pressure Spring - 1/2"
– 3/4" Valve; 100 psi, 316 SS
Pressure Spring - 1
” Valve; 150 psi
Pressure Spring - 1
” Valve; 50 psi
PV-00602
PV-006021
PV-006023
PV-006122
PV-00602S
PV-00603
PV006033
7
Support Disc - 1/2
– 3/4" Valve, PVC
Support Disc - 1/2
– 3/4" Valve, 316 SS
Support Disc - 1
” Valve, PVC
Support Disc - 1
” Valve, 316 SS
PV-00705
PV-00706
PV-00707
PV-00709
8
Diaphragm - 1/2"
– 3/4" Valve - PTFE / EPDM
Diaphragm - 1/2
” – 3/4” Valve – Viton
Diaphragm - 1/2"
– 3/4" Valve - PTFE / Viton (High Temperature)
Diaphragm - 1
” Valve – PTFE/EPDM (4.5” OBS Body)
Diaphragm - 1
” Valve –Viton (4.5” OBS Body)
Diaphragm - 1
” Valve – PTFE/EPDM (5” OD Body)
Diaphragm - 1
” Valve – Viton ( 5” OD Body)
PV-00810
PV-00812
PV-00813
PV-00820
PV-00821
PV-00830
PV-00831
9
Adjustment Screw - 1/2
” – 3/4” Valve PET (white)
Adjustment Screw - 1/2
” – 3/4” Valve Coated Steel
Adjustment Screw - 1
” Valve PET (white)
Adjustment Screw - 1
” Valve Coated Steel
PV-00906
PV-00903
PV-00926
PV-00921
10
Protective Vinyl Cap- 1/2
” – 3/4 ” Valves
Protective Vinyl Cap- 1
” Valves
PV-01001
PV-01002
Note: The 1” High Flow Valves use the same internal parts
as the standard 1 ½” Valves.
The Part #’s BP/PRHF100_ has 4.5” bottom diameter.
The Part #’s BP/PRHF105_ has a 5” bottom diameter.
