C-TECH-I, INC
USERS' GUIDE
2
Installation
1. First, take the rubber washer through the pipe cover. Insert the body into the
faucet hole of the sink (See figure 1 and figure 2);
2. Take the two washers through the pipe cover. Then revolve the locknut onto
the pipe cover and fix the faucet on the sink by the washers ˄See figure 3 and
figure 4 ˅;
3. Install the pull-out spray as follows(See figure 5 and figure 6):
44
37
43
Figure 1
44
37
43
Figure 2
Insert
44
37
43
Figure 3
45
46
37
43
Figure 4
47 48
45
46
Revolve
Figure 5
Insert
1
5
30
Spray
Spray
30
5
37
43
Figure 6
Insert
1
9
2
Check valve inside
Check valve inside
