2. CONNECTIONS
continued …
Example 3: Processor to amplifiers and subwoofer
(Balanced connection shown, single-ended is similar)
To powered
subwoofer
Trigger Setup Suggestion:
If it is not necessary to have both
amplifiers turned on when stereo
sources are playing, set triggers
to turn on only the 2-channel
amplifier when a stereo source is
selected (see section 3.11).
