passenger side.
22. Working on the driver side, re-attach the new upper
control arm to the steering knuckle using the new castle
nut and cotter pin. torque to 90 ft lbs. Repeat procedure on
passenger side.
23. Working on the driver side, locate (1) 1/4” nylock nut and
(1) 1/4” USS flat washer. Attach the OE ABS brake wire
bracket to the new upper control arm. Repeat on passenger
side.
24. Locate Sway bar hardware, re-attach sway bar endlink
to the steering knuckle and torque to 65 ft lbs. Repeat on
passenger side.
25. Locate the front differential mounting points, carefully
remove the (2) OE bolts that connect the front differential
brackets to the front crossmember, save the oversized
washer and discard the bolt and nut.
26. Locate (2) new S10247 Diff drop sleeves, (2) 1/2” x
6” bolts, and (2) 1/2” unitorque nuts from hardwar bag
54910NB. Also locate the OE oversize washers removed
earlier, Install the front differential drop spacers between the
OE brackets and front crossmember. Secure using new 1/2”
x 6” bolts and 1/2” nuts. Torque to 80 ft lbs.
27. Locate (2) S10025 sleeves from sleeve bag 52907SL,and
(2) 8mm x 40mm bolts, and (2) 8mm flat washers from hard-
ware bag 52907NB. Also locate the skid plate and OE skid
plate hardware, Re-install the skid plate using original hard-
ware in the front and new bolts and spacer sleeves in the
rear. Torque 8mm bolts to 12 ft lbs.
