AEG KO_FAVORIT 5071 - Manual (Page 31)

Installation and Connection Instructions
31
Built-In Dishwasher
(see enclosed installation instructions)
Free-Standing Appliances
1 • Can be installed free-standing without additional fixings.
If the dishwasher is installed next to a gas or solid fuel cooker, a non-
flammable panel of thermal insulation must be fitted between the
cooker and the dishwasher, the panel must flush with the upper edge
of the work surface (depth 57.5 cm). The panel should be fitted with
aluminium foil on the side facing the cooker.
• If the dishwasher is to be built-in
under a kitchen work surface, the
work surface fitted to the dish-
washer must be removed as fol-
lows:
– Undo the screws on the angled
brackets on the rear of the appli-
ance (1).
– Slide the work surface approx.
1cm to the rear (2), lift at the
front (3) and remove.
– Press the work surface retaining
brackets at the position shown in
the diagram
(4) and remove the
bracket at an angle to the rear (5).
1 If the dishwasher is subsequently
used as a stand-alone unit again, the
work surface must be re-fitted.
4
5
