Tuff Country 16961 - GM 2006 K1500 4wd 6 kit (w/factory air shocks) - Manual (Page 3)

Hardware bag 16957SL includes:
Description Quantity
S10019 (.750” x .563” x 1.190”) 2
S10058 (.875” x .500” x 2.080”) 4
S10074 (.700” x .563” x 1.500”) 4
S10082 (.875” x .563” x 2.080”) 1
S10110 (.750” x .563” x 9.500”) 2
Hardware bag 16957PL includes:
Description Quantity
PB6199 (bump stop) 2
PB2408 (poly bushing) 2
MO2220 (poly bushing) 8
PB10630018 (Sway bar bushing) 8
S10113 (Sway bar end link washer) 8
SUW-916 (9/16” u-bolt washer) 2
BLR01 (brake line relocation bracket) 2
5161B (5/16” x 1” bolt) 1
14WA (1/4” USS flat washer) 2
516UN (5/16” unitorque nuts) 1
LUBE (poly lube pack) 2
Hardware bag 16957NB includes:
Bag # 1
Description Quantity
3/8” unitorque nuts 2
5/16” USS flat washers 2
3/8” x 3/4” self threading bolts 4
5/16” x 1” bolt 1
10 mm x 55 mm bolts 12
10 mm x 60 mm all thread bolt 4
10 mm lock washers 16
1/4” USS flat washers 2
5/16” unitorque nuts 1
Bag # 2
Description Quantity
7/16” x 1 1/4” bolts 2
7/16” x 1 1/2” bolts 10
7/16” x 3” bolts 1
7/16” unitorque nuts 13
3/8” USS flat washers 26
Bag # 3
Description Quantity
1/2” unitorque nuts 8
1/2” x 15” bolts 2
1/2” x 2 1/4” bolts 2
1/2” x 3 1/2” bolts 4
7/16” USS flat washers 12
Bag # 4
Description Quantity
9/16” x 1 3/4” bolts 2
9/16” x 3” bolts 4
9/16” unitorque nuts 6
1/2” USS flat washers 16
Bag # 5
Description Quantity
5/8” x 4 1/2” bolts 2
5/8” x 5 1/2” bolts 2
5/8” unitorque nuts 4
9/16” USS flat washers 8
Hardware bag 14959NB1 includes:
Description Quantity
1/2” x 1 1/2” bolts 6
7/16” USS flat washers 12
1/2” unitorque nuts 6
Hardware bag 916NW includes:
Description Quantity
9/16” u-bolt high nuts 8
9/16” u-bolt harden washers 8
Special note: Before installation begins, it is the
customers/installers responsibility to make sure that
all parts are on hand. If any parts are missing, please
feel free to call one of our customer service
representatives @ (801) 280-2777.
Special post installation procedure: Tuff Country EZ-
Ride Suspension highly recommends adding a
minimum of 1 pint, but no more that 1 1/2 pints, of
proper front differential fluid into the front differential.
To achieve this, you may have to fill the differential
with it on its side or you may have to insert the fluid
through the vent tube opening. On occasion, the
customer may find burping of fluid coming out of the
front vent tube.
Recommended tools selection:
Torsion bar puller
(Part # 7822A / LSP code: 769 006 21)
Cut off wheel
Sawzall
Torque wrench
Standard socket set
Standard wrench set
Metric socket set
Metric wrench set
Tape measure
Hydraulic floor jacks
