QUICK START GUIDE: SymNet xControl
Assembly
1
1
3
2a 2b
1
Assembled
Linking Blocks
Unthreaded
Linking Block Threaded
Linking Block
One - 1.25” 4-40
Flathead Screw
Four - 0.5” 6-32
Flathead Screws
Four - 0.5” 6-32 Flathead Screws
Four - 0.5” 6-32 Flathead Screws
Rotate Rack Ear Rotate Rack Ear
Four - 0.5” 6-32 Flathead Screws
Four - 0.5” 6-32 Flathead Screws
Four - 0.5” 6-32
Flathead Screws
Four 0.5” 6-32
Flathead Screws
Rack mounting a single device
Rack mounting two devices
Surface Mounting
One - 1.06”
Short Rack Ear
One - 9.625”
Long Rack Ear
One - 1.06” Short Rack Ear One - 1.06” Short Rack Ear
