a) Start the generator and adjust the spear valve to obtain 220-240 volts, 0 amps at the
panel. [Do not turn the circuit breaker on].
b) Adjust the potentiometer on the circuit board very slowly to the left. When you
detect a small decrease in voltage, stop. Turn on the circuit breaker and increase water
to increase power to the unit. Increase power until a load of 2kW is indicated (P =VI).
c) If adjusting the potentiometer does not correct the problem, then contact PowerPal.
The problem is probably with the potentiometer.
TECHNICAL SPECIFICATIONS
MHG-T2
1 Rated power output 2000W
2 Maximum allowable load 2200W
3 Intended voltage 220V~
4 Frequency at rated power output 50 Hz
5 Frequency at runaway speed 70 Hz
6 Runaway speed 1500rpm
7 Height 600mm
8 Weight 90kg
9 Turbine runner type Turgo
10 Runner diameter 270mm
11 Number of buckets 20
12 Number of nozzles 1
13 Generator 3- phase
14 Generator insulation Class B
15 Protection grade IP54
16 Load controller circuit breaker 20A
17 Upper generator bearing size
Lower generator bearing size
Turbine bearing size
6206-2Z
SKF 7206B
SKF 1207
18 Seal size 38x58x10mm
19 Recommended cable 4mm2
20 Operating temperature 5 to 50 ° C
21 Operating humidity 0 to 90%
Notes:
1,2.
Rated power output is the manufacturer’s specified output for the given head
and flow conditions. A higher output is possible if the head is greater or the flow is
faster than recommended. If the maximum allowable load is exceeded then permanent
damage to the stator may occur.
3.
Is approximately 220V when the ELC is used.
5,6.
Runaway speed is the speed of the rotor if no load is applied. This speed is
reduced under load.
18.
We recommend SKF brand or similar high quality bearings.
Also, the diagrams and much useful information on pages 7 and 16 are taken from
Micro-hydropower Sourcebook – A Practical Guide to Design and Implementation in
Developing Countries. NRECA, 1986.
