Speedtech ATS Spindle - Manual (Page 9)

9 | P a g e
Performance Alignment Specifications
Note: These are only suggestions and may need additional changes to
achieve the optimum settings for your driving style or situation.
Daily Driving, Street Performance Specifications
Driver Side Passenger Side
4 Degrees positive Caster 4 ½ Degrees positive Caster
0 to ½ Degree negative Camber 0 to ½ Degree negative Camber
3/ 32 Total Toe-in 3/ 32 Total Toe-in
Aggressive Track Alignment Specifications
Driver Side Passenger Side
5 ½ Degrees positive Caster 6 Degrees positive Caster
½ to 1 Degree negative Camber ½ to 1 Degree negative Camber
3/ 32 Total Toe-in 3/ 32 Total Toe-in
Typical Original Alignment Specifications
**For reference purposes only. Do Not use these specs.
Driver Side Passenger Side
½ Degree positive Caster ½ Degree positive Caster
¼ to ½ Degree negative Camber ¼ to ½ Degree negative Camber
1/8 Total Toe-in 1/8 Total Toe-in
