41
USA/GB
ROX 9.1
5 4 3 2
9 8 7 6
13 12 11 10
20
16 15 14
19 18 17
1 PREFAcE AnD cOnTEnTS OF PAckAGE
k Bracket k Docking station
k
Attachment
fittings
k
SIGMA DATA
CENTER
software CD
2 InSTAllInG ThE SIGMA ROX 9.1 AnD ITS AccESSORIES
Illustrations regarding to these assembly notes can be found in the enclosed folded sheets!
2.1 InSTAllInG ThE BRAckET
k Handlebars or front end
k
Remove yellow film
2.2 InSTAllInG ThE TRAnSMITTERS – SPEED AnD cADEncE
k
Both transmitters can be fitted with cable ties (permanent attachment)
or with the O-rings.
k
To obtain the required gap of 12 mm or less, place the transmitter and magnet
closer to the hub.
1.2 cOnTEnTS OF PAckAGE
2.4 InSTAllInG ThE SIGMA ROX 9.1 TO ThE BRAckET
2.3 InSTAllInG ThE MAGnETS – SPEED AnD cADEncE
