SAFETY PRECAUTIONS
Paragon values your continued safety above all else. Please follow these guidelines when using your equipment to
prevent injury and maximize product performance:
All equipment is designed and sold for commercial use only. Equipment is not to be
used by the general public or intended for home use. No direct contact to equipment
by the general public should be allowed when used in food service locations. Only
trained personnel should operate this equipment.
Carefully read any and all instructions before beginning operation of the equipment.
Any alterations made to equipment by anyone other than certified Paragon personnel
will void warranty and may also create unsafe working conditions. NEVER make
alterations to the equipment.
ASSEMBLY INSTRUCTIONS
CART
1. Attach Handle to the cart body using four 1/4” - 20 x 3/4” bolts, flat washers,
lock washers and hex nuts.
2. Turn assembly over on its top.
3. Install Long Legs to the same side of the cart body that the handle is
attached to using four ¼” – 20 x 2” Screws, flat washers, lock washers, and
hex nuts.
4. Press End Caps into the protruding end of legs.
5. Attach Short legs to the opposite side of the cart body that the handle is
attached to using four ¼” – 20 x 2” Screws, flat washers, lock washers, and
hex nuts.
6. Slide axle rod through the holes in the Short Legs.
7. Slide a wheel over the axle rod on the outside of Short Legs. Put a Clip Pin
through the holes on each end to secure the wheels to the axle.
8. Turn assembly the correct side up and position the Cart Tray over the side of
the cart body opposite of the handle.
3
