S5140 © 04/08 PAGE 2 OF 3
2008 DODGE DAKOTA
Removal of stock system:
1. Apply a penetrating lubricant liberally to all exhaust fasteners,
hangers and rubber insulators.
2. Loosen the clamp behind the muffler remove the tail pipe from
the rubber isolators. Then remove the tail pipe from the vehicle.
Refer to Figures 1 & 2.
3. Remove the clamp in front of the muffler, separate the muffler at the
slip joint and remove from the vehicle. Remove the ground strap from
the exhaust. Refer to Figure 3.
4. Remove the clamp located behind the “Y” pipe and then
remove the hanger from the rubber insulator. Next remove the
front muffler. Refer to Figure 4.
Figure 1
Figure 2
Figure 3
Figure 4
