S6116TD © 11/10 PAGE 2 OF 3
Removal of Stock System:
1. Apply a penetrating lubricant liberally to all exhaust fasteners, hangers and rubber insulators.
2. Remove the exhaust system from the rubber insulators and remove all of the clamps from the system.
3. Separate the slip joint behind the muffler and remove the tail pipe. Next, separate the slip joint located behind the
catalytic converter and remove the muffler and extension pipe. Remove the catalytic converter by separating the slip
joint located between the down pipe and the catalytic converter. Now loosen the band clamp connecting the down
pipe to the turbo and remove the down pipe. Do not discard the band clamp as it is required for the installation.
4. Remove the OEM down pipe hanger bracket from the bellhousing. Do not discard these parts as they are required
for the installation.
5. Remove the spare tire. Remove the exhaust system from the vehicle.
Installation of MBRP Inc. Performance Exhaust:
Note: This exhaust is intended to be used on a lifted vehicle with the spare tire
removed.
1. Slide the OEM down pipe hanger bracket onto the Down Pipe hanger.
Install the Down Pipe in the same position as the stock down pipe by
reattaching the hanger bracket to the bellhousing and then attaching the
flared end to the turbo using the stock band clamp. Do not fully tighten until
all components are in place. Refer to Figure 1 & 2.
Figure 1
Figure 2
