S6004 © 12/09 PAGE 4 OF 4
7. Install the Tail Pipe from the rear of the truck, over the axle and
attach to the Muffler Outlet. Install the Tail Pipe Hanger into the
OEM hanger, adjust for best axle clearance and Tail Pipe location
to complete. See Figure 11.
8. Install the Hanger Clamp with the longest hanger at the
connection between the Muffler and the Tail Pipe and into the
OEM rubber hanger at this position. See Figure 12.
9. Install remaining Clamps around pipes as shown in the opening
diagram. Adjust Tail Pipe and check along the whole length of the
exhaust system to ensure that there is adequate clearance around
the spare tire, fuel and brake lines or any wiring. If any interference
is detected, relocate or adjust.
10. Make sure the exhaust is in place before tightening clamps. Start
at the front of the exhaust system and begin tightening all
connections.
11. Install and adjust Tip to suit. Using a 17mm wrench tighten lock
bolt located on Tip.
Congratulations! You are ready to begin experiencing the improved power, sound and driving excitement of
your MBRP Inc. performance exhaust system. We know you will enjoy your purchase.
Figure 11
Figure 12
