MBRP S6206 User Manual

Page 2

S6206304

“PRO

SERIES”

S6206AL

“Installer

Series”

S6206409 “XP SERIES”

1 PC - Down Pipe

1 PC - Mid Pipe

1 PC - Extension Pipe

1 PC - High Flow Muffler

1 PC - Tail Pipe

PCS

- 3.5" Clamps

2 PCS - 3.5" Clamps

4 PCS - Hanger Clamps

1 PC - Gasket

1 PC - 5" Stainless Steel Tip

Tips Sold Separately

Removal of Stock System:

1. Apply a penetrating lubricant liberally to all exhaust fasteners, hangers and rubber insulators.

2. Loosen the nut on the band clamp located behind the catalytic converter
using a 15mm wrench or socket. See Figure 1.

3. Remove the muffler and tail pipe from the OEM rubber hangers. To
remove the system in one piece, on 03-04 models, the bottom shock bolt

of the passenger side shock must be removed. This is not required on
05 or 06 models. Separate the stock exhaust at the slip joint located

Figure 1

behind the catalytic converter and remove the muffler and tail pipe from

under the truck. Re-install the bottom shock bolt.

4. Remove the catalytic converter by removing the two nuts holding the
inlet

flange together using a 15mm wrench or socket. Retain the nuts for the
re-installation of the catalytic converter. See Figure 2.

Figure 2

S6206

12/05

Page
