UT1001, UT2001 © 07/09 PAGE 3 OF 3
7. Set the T-Pipe Assembly at the desired height from the floor of
the bed (This will set the height of the Stacks). Using spacers to
hold the T-Pipe at the desired height, loosely attach the Stacks to
the Stack Mounting Brackets making sure that they are straight.
This will hold the assembly steady while you line the system up to
the exhaust under the vehicle. Refer to Figure 5.
8. Measure from the T-Pipe slip joint to the exhaust system that you
are connecting to. Mark and cut the shorter side of the 20” Elbow
to the required length so that it lines up with the vehicle’s exhaust
system. Cut the vehicle’s exhaust system in a place where the
Flex Pipe can be placed between the exhaust system and the 20”
Elbow. It may be necessary to cut the 20” Elbow again as well as
cut the Flex Pipe. Refer to Figure 6.
9. Attach the 20” Elbow to the T-Pipe slip joint and then attach the
Flex Pipe to both the 20“ Elbow and the vehicle’s exhaust
system. Be sure to slide the required Clamps over the 20” Elbow
and Flex Pipe before connecting it to the vehicle’s exhaust
system. Refer to Figure 7.
10. Make sure that the Stack Mounting Brackets are centered on
the Stacks and tighten the fasteners holding the Stack Mounting
Brackets to the front of the truck bed. Tighten all the Clamps
making sure that the Stacks remains properly aligned.
Shown with 6” x 36” Stacks (B1610)
Congratulations! You are ready to begin experiencing the improved power, sound and driving excitement of
your MBRP Inc.
“ Smokers Smokers Smokers Smokers ™” ™” ™” ™”
. We are certain you will enjoy your purchase.
Figure 5
Figure 6
Figure 7
