Page 8: Technical data

ENGLISH
USER MANUAL
6
FLOORTEC R 360 P
146 2598 000(1)2005-03 A
UNDER HOOD
(See Fig. U)
1.
Serial number plate/technical data/EC certification
2.
Petrol engine model
3.
Petrol engine serial number
4.
Hood (open)
5.
Hood support rod
6.
Petrol engine
7.
Ignition spark plug
8.
Engine choke lever
9.
Petrol tap
10. Fuel tank
11. Fuel tank cap
12. Petrol engine air filter
13. Accelerator lever (adjusted by the Manufacturer: do
not tamper with it nor use it to change the engine
speed!)
14. Filling and engine oil level check plug
15. Engine oil drain plug
16. Petrol engine belt
17. Main broom belt
18. Main broom drive pulley
19. Vacuum fan
20. Petrol engine silencer
21. Batteries
22. Battery caps
23. Lamellar fuse box (services)
24. Circuit breaker
25. Starter and dynamo
26. Manual vacuum system (optional)
27. Switch for machine pushing
28. Battery installation diagram
29. Dynamo fuse
30. Engine air conveyor
(See Fig. V)
1.
Petrol tap
(See Fig. W)
1.
Engine choke lever
TECHNICAL DATA
General
Values
Machine length
1,255 mm
Machine width (without side brooms)
795 mm
Height (steering wheel with knob)
1,173 mm
Working width (with/without side brooms)
1,000/600 mm
Minimum ground clearance (skirts not
included)
40 mm
Main broom size
Ø 265 mm x 600 mm
Side broom size
Ø 420 mm
Front drive and steering wheel
Ø 200 x 50 mm
Rear wheels
Ø 250 x 50 mm
Total machine weight (with batteries)
284.31 Kg
Maximum forward/backward speed
5.5 Km/h / 4.4 Km/h
Gradeability
16%
Hopper capacity
36 L
Main broom and fan motor
350W
Side broom motors
60W
Drive motor
400W
Filter-shaker motor
12W
Cleaning rate (with main broom)
3,060 m
2
/h
Cleaning rate (with main and side brooms)
5,100 m
2
/h
Sound pressure level (L
pA
)
77.4 dB(A)
Batteries
Values
Battery voltage
24V
Starter batteries
2x12V/80 Ah
Petrol engine
Data
Make
Honda
Model
GX100
Displacement
98 cm
3
Engine power
2.2 kW
Specific petrol consumption
327 g/kW-h
NOTE
For other petrol engine data/values, see User's
Manual.
Dust vacuuming and filtering
Values
Dust filter (one side)
3 m
2
Main broom compartment vacuum
18.3 mm H
2
O
