SPECIFICATIONS
Vacuum Tubes: 2 x 12AT7WA, 2 x 12AU7WA
2 x 6414, 2 x 6GF7A, 2 x OA2
Phono Tubes 2 x 6072, 2 x 12AX7WA
2 x 12AT7WA,
Fuse type 120VAC operation: MDL1, 1 AMP / 250 Volt
220VAC operation: MDL1, 1 AMP / 250 Volt
SLO-BLO
Maximum Gain (AUX, TUNER, VIDEO, TAPE) 19 dB at max Volume (min FB)
(1 volt in = 5 volts out)
(BALANCED INPUT) 20 dB
(CD) 13 dB
(PHONO) ( if available)(both MC & MM) 55 dB @ 1KHz
Gain Steps (volume control) 24 x 2 dB except extremes
(-
∞
,-60,-50,-46, -44,-42,-40,-38,-36,-34, -32,-30,-28,-26,-24,-22,-20,-18,-16 -14,-12,-10, -6, 0)
Volume control "Left / right tracking" 1/10 dB typical
Gain adjustment via BALANCE 8 dB nominal
Noise Floor typically -70 dB (20 to 30 kHz)
Maximum output typically +30 dBv
Signal to noise typically 105 dB A WGT 20-20K
Frequency Response 5 Hz to 90 kHz @ +/- .6 dB
Distortion THD+N = -80 dB (.01 %)
zero "crossover" distortion, mostly 2nd harmonic, unmeasurable after 5th
typical of pure Class A1, minimal feedback designs.
Output Impedance MAIN 30 ohms
TAPE 1000 ohms
Power Consumption 170 Watts (1.4 A @ 120VAC)
Size preamp (not including handles, feet) 19" x 11.5" x 5.25"
power supply (not including, feet) 19" x 10" x 2.5"
Shipping Weight (includes box, cables, etc.) 38 lbs
