SPECIFICATIONS
Input Impedance: 110 Kohm
Input Sensitivity:
TRIODE UL
FB MIN: 175mV 155mV
FB STD: 312mV 340mV
FB MAX: 480mV 566mV
Gain: 29dB
Negative Feedback: MIN= 3dB; STD=6dB; MAX=10dB of global NFB
Max. Output Power defined as power output reaching 1.5% THD @ 1KHz
into 5 ohms:
TRIODE UL
FB MIN: 18W 20W
FB STD: 27W 42W
FB MAX: 28W 46W
into 8 ohms: TRIODE UL
FB MIN: 14W 24W
FB STD: 24W 40W
FB MAX: 25W 41W
Signal to Noise Ratio Ref. 1W: Typically 82 dB A-WGT 20-20K
Noise Floor: Typically 150µV = -74dBu A-WGT
Typically 650µV = -62dBu unweighted
Dynamic Range: 83dB
THD+noise @ 5W less than 0.15%
Frequency Response at full power UL mode w/MAX NFB: 20 Hz to 20 kHz FLAT
Frequency Response at 5W into 5 ohms: 10 Hz to 30 kHz FLAT, -3.75dB @ 100KHz
Recommended Speaker Load: Optimized for 5 ohms
Actual Output Impedance: TRIODE UL
FB MIN: 2.83 ohms 3.57 ohms
FB STD: 1.87 ohms 2.16 ohms
FB MAX: 1.28 ohms 1.36 ohms
Power Consumption (idle): 102 Watts (0.85A @ 120VAC)
Power Consumption (at Rated Full Power): 168 Watts (1.4A @ 120VAC)
Vacuum Tubes: 1 x 12AT7WA Ei, 1 x 6414 JAN NOS, 4 x EL84 Output per monoblock
Output Tube Quiescent Standing Current: 25mA
Set Bias for 250mVDC measured across each 10 ohm cathode resistor
Fuse types for 120VAC operation:
MDL or MDA 3 AMP / 250 Volt SLO-BLO
240VAC operation: MDL or MDA 2 AMP / 250 Volt SLO-BLO
B+ FUSE: MDA 4/10th AMP, 250 Volt SLO-BLO
Dimensions: 11" deep x 10" wide x 5" tall
Shipping weight each: 18 pounds
Specifications subject to change because they just might.
