13

SPECIFICATIONS

Maximum Input (Bypass through Line Amplifier)

+30 dBv

Maximum Output

+30 dBv

Headroom (referenced to +4 dBv)

26 dB

Frequency Response:

10 Hz to 70 kHz +/- 0.5 dB

THD & Noise (1kHz @ +4 dBm)

.015%

Noise Floor (Gain set to minimum)

-80 dB Wideband

Signal to Noise

116 dB typical (A wgt)

Maximum Gain (via trim on back)

5 dB to -5 dB

Maximum EQ Boost

16 dB lows, 11- 20 dB highs (see curves)

Maximum EQ Cut

20 dB lows, 11- 21 dB highs (see curves)

Power Consumption

.35 Amps @ 115 VAC

Fuse

1 Amp Slo-Blo

Size (1U)

19" x 1.75" x 10"

Actual Weight

9 Lbs

Shipping Weight

12 Lbs
