Specifications
CS2DU/CU
INPUTS
Compatible microphones:
CK31, CK32, CK33, CK47,
or CK80 in conjunction with GN30CS
or GN50CS
Type: Unbalanced, with DC supply voltage
Input impedance: 1.5 k Ω
Supply voltage: 5.5 V DC
Max. input level for <1% Thd, V out <+3 DB:
25 dB
OUTPUTS
LINE
Connector: 15-pin male HD D-sub
Type: Transformer balanced, floating
Rated output level: +10 dBu
Audio bandwidth: 55 to 35,000 Hz
S/N Ratio, 22 to 22 kHz, QPK:
81 dB
System compatibility: Microphone Station input on Base
Station, compatible with CS 1
THD @ 1kHz: 0.25%
EIN with noise gate, 22 Hz to 22kHz; QPK:
-105 dBu
HEADPHONES AND BUILT-IN SPEAKERS
Headphones connectors: 2 x mini TRS jacks
Output power for <1% THD:
0.48 W
Min. headphones load impedance:>8 Ω
Audio bandwidth: 30 to 45,000 Hz
S/N, 22 to 22 kHz, QPK: 81 dB
THD @ 1 kHz: 0.25%
Equivalent noise level with noise gate, 22 Kz to 22 kHz:
-92 dBu
Digital potentiometer attanuation:
32 stages from 0 to –42 dB linear,
–82 dB max.
SYSTEM
Adjustable functions: Voice activation threshold
Voice activation hold time
Microphone automute ON/OFF
Enable/disable NOM limitation
Voice activation ON/OFF
Priority level
Compression ON/OFF
"Voice zoom" ON/OFF
Headphones/speaker volume
reset/last setting
Adjustable compression
Operating voltage: 23 to 36 VDC
Current consumption: 35 to 63 mA
Max. power requirement: 1.9 watts
Size (lxwxh, Desktop version):
1.0 x 6.0 x 2.9 in. (257 x 153 x 74 mm)
Net/shipping weight: 2.1 lbs. / 3.3 lbs. (950 g / 1500 g)
Finish: Blue Line gray / matte black
Package contents: Station without microphone and cables
Specifications
CS2BU
INPUTS
MICROPHONE STATIONS
Connector: 4 x 15-pin male HD D-sub
Input level: +10 dBu (compatible to CS 1)
Type: Electronically balanced
Max. input level for <1% THD:
+13 dB
LINE
Connector: 3-pin female XLR
Input level: ±0 dBu
Type: Transformer balanced
Input impedance @ 1 kHz:
30 k Ω
Max. input level for <1% THD:
17 dB
AUX
Connector: 2 x female RCA
Input level: -10 dBu
Type: Unbalanced
Input impedance @ 1 kHz:
33 k Ω
Max. input level for <1% THD:
+15 dB
OUTPUTS
RECORD
Connector: 2 x female RCA
Output level: ± 0 dBu
Max. output level for <% THD:
+17 dBu
Audio bandwidth: 15 to 50,000 Hz
Min. load impedance: 500 Ω
THD @ 1kHz: 0.01%
S/N, 22 to 22 KHZ, QPK: 88 dB
LINE
Connector: 3-pin male XLR
Output level: ±0 dBu
Max. output level for <% THD:
+10 dBu
Audio bandwidth: 20 to 40,000 Hz
Min. load impedance: 300 Ω
THD @ 1kHz: 0.02%
S/N, 22 to 22 KHZ, QPK: 88 dB
HEADPHONES
Connector: 1/4" TRS jack
Bandwidth: 17 to 25,000 Hz
Output level: ±0 dBu
Max. output level for <% THD:
+14 dBu
Min. Impedance: 150 Ω
THD @ 1kHz: 0.05%
S/N, 22 to 22 KHZ, QPK: 82 dB
