Axis Video Server Installation Guide Page 5
ENGLISH
Overview
DIP switches
LED indicators for Network, Status & Power
Video input (x4) Control button
Line/Mic In &
Line Out
(241QA only)
Front panel - AXIS 240Q/AXIS 241Q/AXIS 241QA
Video input
Control button
Mic In & Line In
Video output
S-Video (Y/C) input
DIP switch
DSP & IV LED indicators
Front panel - AXIS 242S IV
LED indicators for Network, Status & Power
Video input
Control button
Line/Mic In
& Line Out
(AXIS 243SA
only)
Video output
DIP switch
Front panel - AXIS 241S/AXIS 243SA
LED indicators for Network, Status & Power
Power adapter
connector
12-pin I/O terminal
connector
RS-232
connector
Network
connector
Rear panel - all models
Serial number on underside label
