Page 4 Axis Video Server Installation Guide
Mounting
The Axis Video Server is supplied with a mounting kit for wall or rack mounting. The
mounting brackets can be positioned for mounting the video server on a vertical surface or in
a rack (4U). Follow the instructions below to attach the brackets to the video server:
Position and attach the brackets on each
side, using the screws provided.
Insert the metal plates in the slots on
each side of the video server.
Slide the grey frame off the front panel
of the video server (no tools needed).
Alternative A
Alternative B
1
2
3
