AMERICAN DYNAMICS AD9517B 17-INCH COLOR MONITOR

VS206-02 03/03 A4E

Product specifications and availability subject to
change without notice.
Certain product names mentioned herein may be trade
names and/or registered trademarks of other companies.

SPECIFICATIONS

Model Number

AD9517B . . . . . . . . . . . . . . . . . . . . . Monitor, Color, 17 in, 280 TV lines

composite, (>750 TVL Y/C), NTSC/PAL

Operational

Picture Tube . . . . . . . . . . . . . . . . . . 43.18 cm (17 inch diagonal), 90°

deflection, flat-square type CRT

Resolution . . . . . . . . . . . . . . . . . . . >750 TV lines Y/C

450 TV lines composite NTSC/PAL

Comb Filter . . . . . . . . . . . . . . . . . . Internal
Video Input Level . . . . . . . . . . . . . 1.0 Vp-p, composite NTSC/PAL
Impedance . . . . . . . . . . . . . . . . . . . HiZ/75 Ω, auto termination
Audio Output . . . . . . . . . . . . . . . . 1.0 watt

Front Panel Controls

Phase (Tint) . . . . . . . . . . . . . . . . . . Adjusts picture to obtain most natural

colors (skin tones), NTSC only

Chroma (Color) . . . . . . . . . . . . . . Adjusts depth of saturation of color
Brightness . . . . . . . . . . . . . . . . . . . Adjusts overall shading of picture and

establishes picture brightness

Contrast . . . . . . . . . . . . . . . . . . . . . Adjusts relationship between light and

dark areas of picture

Menu . . . . . . . . . . . . . . . . . . . . . . . . Provides access to the on screen set-up

Volume +/- . . . . . . . . . . . . . . . . . . . Adjusts volume higher and lower
Video A . . . . . . . . . . . . . . . . . . . . . . Selects video input A
Video B and Y/C . . . . . . . . . . . . . . Selects between composite video B and

Y/C input

Under Scan . . . . . . . . . . . . . . . . . . . Switches between normal and under scan
Power . . . . . . . . . . . . . . . . . . . . . . . . Turns monitor on and off

Connectors

Video A & B . . . . . . . . . . . . . . . . . . Two sets of 2 BNC connectors for loop-

through operation with auto termination

Audio A & B . . . . . . . . . . . . . . . . . . Two sets of 2 RCA connectors for loop-

through operation

Y/C Connector . . . . . . . . . . . . . . . Four pin Mini-DIN pair for loop-through

operation

AC Input Connector . . . . . . . . . . IEC 320 type connector for AC input

Power Cables

North American . . . . . . . . . . . . . . NEMA 5-15P, UL, CUL
Continental European . . . . . . . . CEE 7/7, GS*
*UK and Australian power cords ordered separately.

Electrical

Supply Voltage . . . . . . . . . . . . . . . 120 - 230 VAC

(50/60 Hz), ±10%

Power . . . . . . . . . . . . . . . . . . . . . . . . 75 watts

Mechanical

Dimensions (H x W x D)

Cabinet . . . . . . . . . . . . . . . . . . . . 33.4 x 39.5 x 41.81 cm

(13.15 x 15.55x 16.46 in)

Rack Mount . . . . . . . . . . . . . . . 39.9 x 48.3 x 40.64 cm

(15.75 x 19 x 16 in)

Unit Weight . . . . . . . . . . . . . . . . . . 19.6 kg (43.21 lbs)
Shipping Weight . . . . . . . . . . . . . 20.4 kg (44.97 lbs)
Color . . . . . . . . . . . . . . . . . . . . . . . . Black
Construction . . . . . . . . . . . . . . . . . Metal cabinet

Environmental

Operating Temperature . . . . . . . 0° to 40° C (32° to 104° F)
Humidity . . . . . . . . . . . . . . . . . . . . 20 to 80% RH (non-condensing)
Storage Temperature . . . . . . . . . . -25° to 50° C (-13° to 122° F)

Regulatory

Emissions . . . . . . . . . . . . . . . . . . . . USA/FCC: Part 15, Subpart B, Class B

CE: EN55022
EN61000 -3-2
EN61000 -3-3
Canada: ICES-003 (Class B)
Meets Australia/New Zealand EMC

Immunity . . . . . . . . . . . . . . . . . . . . CE: EN50130-4
Safety . . . . . . . . . . . . . . . . . . . . . . . . UL: UL1950

CSA: 22.2, No. 950
CE: EN60950: 2000
DHHS: Rules 21 CFR, Subchapter J ROV

Accessories

AD9517RK . . . . . . . . . . . . . . . . . . Rack Mount Kit
