Ashland 50 - Manual (Page 9)

KEY NO. PART NO. DESCRIPTION
1 A45005 Actuating frame
2 A45006 Pin, 1-1/4" x 2-9/16" w/ locking head
3 Bolt, 5/8" x 1-1/4" NC w/ lock nut
4 A2502 Pin, 1-1/2" x 5-3/4"
5 Capscrew, 1/2" x 1" NC w/ LW
6 A4524 Pin, 1-1/8" x 6"
7 A30003 Shoulder pin, 2-1/2" shoulder, 1-1/4" to 1"
Nut, 1" NF lock nut
8 A30002 Roller
9 Cotter pin, 1/4" x 2"
10 A6007A Pin, 1-1/4" x 4-1/8" w/ sq. head & hole for gr. zerk
11 A45007 Actuating arm, left
A45008 Actuating arm, right
9
