6
SECTION II
SPECIFICATIONS AND DIMENSIONS
A. SPECIFICATIONS
NOTE: ADC reserves the right to make changes in specifications at any time without notice or
obligation.
Gas
Maximum Capacity (Dry Weight) 670 lb 303.9 kg
Basket Diameter 78-1/4" 198.8 cm
Basket Depth 92" 233.7 cm
Basket Volume 256 cu ft 7.25 cu m
Blower Motor 2 x 5 hp 2 x 3.73 kW
Basket Motor 25 hp 18.7 kW
Door Sill Height, Level 52" 132.1 cm
Compressed Air Volume (1-way / 2-way tilt) 15/19 cfh 0.42/0.54 cmh
Compressed Air Connection 1/2" F.N.P.T.
S.A.F.E. Water Connection* 1" F.N.P.T.
Voltage Available 208-480v / 3Ø / 3,4w / 50/60 Hz
Heat Input 2,200,000 Btu/hr 554,400 kcal/hr
Approx. Shipping Weight 9,200 lb 4,173 kg
Airflow 13,000 cfm 368 cmm
Inlet Pipe Connection** 2" F.N.P.T.
061103
* Water supply must be 40 psi +/- 20 psi (2.75 bar +/- 1.37 bar) for S.A.F.E. system to operate properly .
** Size of piping to dryer varies with installation conditions. Contact factory for assistance.
