American Fibertek Series USB 2.0 Fiber Optic Extender - Manual (Page 12)

12
Specifications
Range 10km over SMF, 1km over MMF
USB device support
High-speed devices (480 Mb/s) (USB 2.0)
Full speed devices (12 Mb/s) (USB 2.0 & 1.1)
Low-speed devices (1.5 Mb/s) (USB 2.0 & 1.1)
USB hub support Any single chain can include up to 3 USB hubs plus one Product Name.
Maximum USB devices
supported
14 USB Devices or 3 USB hubs with 11 USB devices.
AC adapter(s)
Input: 100/240V AC, 50 - 60 Hz, 600mA maximum
Output: 5V DC, 3 A
AC adapter connector 1.7mm centre-positive jack
Power available to USB
device at MTX unit
500mA each port
MRX/RRX unit USB
connector
1 x USB Type B
MRX/RRX unit Link
connector
1 x Duplex LC
MTX unit Link connector 1 x Duplex LC
MTX unit USB connector 4 x USB Type A
MRX/RRX unit dimensions 3.94 X 2.99 x 1.02 Module, 6½ x 5 x 1 Rackcard
MRX/RRX power
consumption
500mA Maximum
MTX unit dimensions 3.94 X 2.99 x 1.02 Module
MTX power consumption Approx. 500mA (No load). 2.5A (Full load)
System shipping weight 2.0lbs. (0.9kg)
Operating temperature range 0 C to 60 C
Storage temperature range -20 C to 70 C
Operating humidity 20% to 80% relative humidity, non-condensing
Storage humidity 10% to 90% relative humidity, non-condensing
Regulatory testing FCC (Class B), IC (Class B), CE (Class B)
ESD rating EMC EN-61000-4-2 8kV Contact, 16kV Air
