American Fibertek MRR-860 User Manual
Page 6
6
MRT-860 STATUS INDICATORS
The MRT-860 transmitter provides the following front panel LED status indicators to aid
in installation and troubleshooting:
VIDEO
A bi-color LED indicator is provided for each of the six video channel inputs. AC power
and video status associated with each of these LEDs are summarized below.
Video Presence LED
AC Power Status
Video Status
Green
On
Proper Input Video Present
Red
On
Input Video Not Detected
Off
Off
Check Power Supply Input
