Ag-Bag International, Ltd.
MB901012 HyPac September 2003
Appendix A
Rotor Group - Parts List
Item# Part# Description Qty. Remarks
1 ref. Cap Screw, Hex Head 4 7/8-9 NC x 5-1/2 G8
2 ref. Cap Screw, Hex Head 7 1-8 NC x 3 G8
3 1202032 Mount, Rotor Idle Bearing 1
4 ref. Nut, Hex Head 7 1-8 NC Nylock
5 ref. Nut, Hex Head 4 7/8-9 NC Nylock
6 ref. Cap Screw, Hex Head 10 1/2-13 NC x 2-1/4 G8
7 1120496 Sprocket, Beater Bar Drive - Rotor 1
8 1202030 Seal, Rotor Cover 2
9 ref. Washer, Flat 8 3/8 SS
10 ref. Nut, Hex Head 4 3/8-16 NC SS
11 ref. Nut, Hex Head 10 1/2-13 NC Nylock
12 1202029 Rotor Tube Weldment, No Teeth 1
1202046 Rotor Stub Shaft 1
1020049 Tooth, Rotor 104
1501666 Adhesive, rotor tooth cap install 2
13 1510210 Bearing, 4-Bolt Flange 1
14 ref. Cap Screw, Hex Head 4 3/8-16 NC x 6 SS
15 1020021 Cap, rotor tooth - cast alloy 104
16 ref. Pin, slotted spring 104 3/8 x 1
17 ref. Pin, slotted spring 104 5/16 x 1
18 ref. Nut, Hex Head 12 1-8 NC Nylock
19 ref. Cap Screw, Hex Head 2 M16 x 55
20 ref. Washer, Spring 2
21 ref. Cap, Output Billet Retaining 1
22 4070146 Billet Planetary Output 1
23 ref. Cap Screw, Hex Head 12 1-8 NC x 5 G8
24 ref. Nut, Hex Head 18 3/4-10 NC Nylock
25 1520796 Planetary 1
26 1502074 Breather, Oil 1
27 1501758 Gauge, Sight - Fluid Level 1
28 ref. Cap Screw, Hex Head 12 3/4-10 NC x 7 G8
29 ref. Cap Screw, Hex Head 12 1/2-13 NC x 2 G8
30 ref. Washer, Spring 12 1/2
31 ref. Seal, O-ring 1
32 ref. Nut, Hex Head 8 1/2-13 NC Nylock
33 4070147 Billet, Planetary Input 1
34 4070149 Housing, Planetary Drive Shaft 1
35 ref. Cap, Input Billet Retaining 1
36 ref. Washer, Spring 2
37 ref. Cap Screw, Hex Head 2 M10 x 30
38 ref. Washer, Spring 8 5/8
39 ref Cap Screw, Hex Head 8 5/8-11 x 2 G8
40 4070148 Shaft, Planetary Drive 1
