PM-30
Ag-Bag® International
June 1999
CT-5
FRAME GROUP
KEY PART NO.
PART NAME
QTY
REMARKS
1
1580085
EXTENSION, HOPPER
1
TUNNEL END BOLT ON
2
1550063
CAP SCREW, HEX HEAD
5
3/8-16 NC X 3-1/2 G5
3
1550147
NUT, HEX
8
3/8-16 NC NYLOC
4
1580110
SPACER
2
BAG PAN CRANK HANDLE
5
1580111
CRANK, LEVER
2
BAG PAN LIFT
6
1550058
CAP SCREW, HEX HEAD
2
3/8-16 NC X 1-1/2 G5
7
1550206
WASHER, FLAT
6
3/8
8
1550303
NUT, HEX
2
3/8-16 NC NYLOC JAM
9
1550063
CAP SCREW, HEX HEAD
2
3/8-16 NC X 3-1/2 G5
10 1550148
NUT, HEX
2
5/8-11 NC NYLOC
11
1550315
CAP SCREW, HEX HEAD
2
5/8-11 NC X 2 G5
12 1580112
BAG PAN
1
13 1580113
FRAME
1
14 1550145
NUT, HEX
4
1/2-13 NC NYLOC
15 1550202
WASHER, FLAT
4
1/2
16 1500192
JACK
1
MANUAL 7000LB. W/MOUNT
17 5802084
GAUGE WHEEL
1
18 1580114
TOW HITCH
1
19 1550172
PIN, HITCH
2
5/8 X 6-1/2
20 1580115
CONTAINER, PIPE REEL
1
