5
VOLUME UP/DOWN
Changes the volume
level of the product,
normally the TV.
NUMBERS
Enter numbers for direct
channel selection. Some
products require ENTER
to be pressed after
channel selection.
ON•OFF Turns
product On or Off.
CHANNEL Up/Down
Changes the channels.
Button Functions, cont.
SETUP Used to setup the remote,
and for code search function.
SHIFT Press and release to access buttons
labeled in reverse print (OK, MENU,
EXIT). See “Using SHIFT for Menu and
Navigation” description on Page 9
for more information.
Note: The REC button must be pressed TWICE to record from
your VCR. For some brands of VCRs, you might need to press
the
REC button once, then press it again for three seconds.
ENTER
For some TV models,
used after direct
channel number
entry to immediately
change to the
selected channel.
MUTE Turns off the
TV sound while the
picture remains.
OK Selects menu
items for the device
you are controlling.
SLEEP enables the remote to
turn off your TV after a period
of 1 to 99 minutes.
EXIT Exits On-Screen Menus
and/or Returns to previous On-
Screen selection.
