5
Wall Installation
1 Reverse the handset tab.
INSTALLATION
Modular
telephone
wall jack
Channel
Telephone line jack
Mounting area
Line Cord
3 Feed the line cord into the channel and wind it
around and out of the mounting area as shown.
4 Connect the other end to a wall jack.
5 Mount the phone on the wall as shown.
6 Follow Steps 4 and 5 in “Table/Desk Installation.”
Your phone will work immediately after installation
using the default feature settings (see “Feature
Settings Summary” on the next page).
NOTE: If you subscribe to Caller ID services from
your local telephone service provider, you must
follow the instructions in “Set Home Area Code”
on page 7 for your phone to properly recognize
and dial calls, and you may need to follow the
instructions in “Set Local Area Codes” on page 8.
2 Plug one end of the short line cord into the
telephone line jack.
