4
Installation Instructions
Place the top bracket on the top of the microwave
oven, with the tabs on the top and sides of the
bracket fitting squarely against the microwave
oven.
Drill pilot holes through the holes in the top
bracket. Attach the top bracket to the cabinet
using nine bronze round-head screws.
A
B
INSTALL THE TOP BRACKET 5
Tabs
Your trim kit is now fully installed. Replace any
loose items that were removed from the inside
of the microwave oven. Save or discard the extra
screws. Do not place them in the microwave oven.
Keep these installation instructions for future
reference.
Replace house fuse or close circuit breaker to
restore power at the service panel.
A
B
REPLACE ANY LOOSE ITEMS 7
Part No. 164D3370P243
Pub. No. 49-40303
10-02 JR Printed in Korea
C
Place the trim frame over the microwave oven.
Snap the two spring clips on the trim frame into
the slots on the top bracket.
Open the microwave oven door. Secure the trim
frame using four screws (two round-head screws
on the inside top and two flat-head screws on the
inside bottom, colored to match your trim kit).
A
C
INSTALL THE TRIM FRAME 6
B
Spring Clips
Slots
Flat-head screws
(color-matched to your trim kit)
Tabs
Screws
Round-head screws
(color-matched to your trim kit)
