User’s Manual
12
Alarm I/O & RS485
The unit provides an alarm I/O and RS485 port that offers user the flexibility
required to connect the unit to the other device.
Pin Definition Pin Definition
1 Ground 17 Alarm In 1
2 Normal Close 1 18 Alarm In 2
3 Common Node 1 19 Alarm In 3
4 Normal Open 1 20 Alarm In 4
5 Ground 21 Alarm In 5
6 Normal Close 2 22 Alarm In 6
7 Common Node 2 23 Alarm In 7
8 Normal Open 2 24 Alarm In 8
9 Ground 25 Alarm In 9
10 Normal Close 3 26 Alarm In 10
11 Common Node 3 27 Alarm In 11
12 Normal Open 3 28 Alarm In 12
13 Ground 29 Alarm In 13
14 RS485 D+ 30 Alarm In 14
15 RS485 D- 31 Alarm In 15
16 Ground 32 Alarm In 16
VGA Out
A VGA output connector is offered for connecting to a VGA main monitor. The
source of image of VGA and BNC main monitor are the same.
RS-232C
The unit provides a RS-232C communication port for sending and receiving
signals.
USB Connector (x2)
There are two USB2.0 ports on the rear panel for users to connect external
USB devices to the unit, such as ThumbDrive
® or CD-RW.
AVE DR16X / AVE DR8X series unit allows users to preset the OSD settings
using a USB mouse.
