Installation instructions, Parts included – GE AEE24DS User Manual
Page 8
8
Installation Instructions
Window
locking bracket
(1)
Top
mounting
rail
Sill angle
bracket (2)
Right
accordion
panel
Foam top window
gasket (1)
Left
accordion
panel
Window
sash seal
PARTS INCLUDED
(Appearance may vary)
Top rail gasket (1)
Type A
screws (10)
Type C
screws (5)
Type E bolt
with nut (4)
V-supports (2)
Type F bolt
with nut (2)
Side rail (2)
