4. After program loading is complete, the display reverts to either
preview channel 001 (if the system is being activated for the
first time), or it will return to the last XM® channel being used
when the system was turned off. A typical channel display will
appear as shown below.
Typical Channel Display
NOTE: If program reception is noisy or contains audible back-
ground static, switch your radio to another FM frequency.
Refer to Direct FM Frequency Selection later in this
manual for details on how to select another FM
frequency.
SELECTING A SATELLITE CHANNEL
A satellite channel can be selected in three ways; namely, by scrolling
station-by-station, by selecting a group or category or by direct access.
Functional Operation
Functional operation of the system is controlled by the buttons on the
SCU; i.e., the sequence in which they are pressed, and the length of
time button activation occurs.
POWERING UP THE SYSTEM
After the system has been properly installed and activated, the system
can be powered on in the following manner:
1. Turn on the existing vehicle radio and tune the radio to the
selected FM frequencies between 88.1MHz and 89.3MHz; if you
are not sure which frequency to select on your existing radio,
use the existing radio’s SEEK, SCAN or TUNE function to tune
through the frequencies until the satellite signal is played
through the speakers.
NOTE: The default FM frequency is 88.5MHz.
2. Enter this frequency into memory using one of the preset but-
tons on the existing radio, making a note of the FM band and
preset number.
Typical Car Radio
3. At the Satellite System Control Unit (SCU), momentarily press
the Power On/Off button ( ); the Audiovox logo appears and
then slowly fades out. This may be followed by the LOADING
message on the display. This display indicates that the
system is acquiring and loading the satellite information.
5
The Audiovox Logo Appears-and-XM® Satellite Program is Loaded
SFT
0
4
7
1
5
8
2
6
9
3
AUDIO OX SFT
0
4
7
1
5
8
2
6
9
3
AUDIO OX
L OA D I N G
CAR COMPACT DISC PLAYER
LOUD
EQ
SEL
MUTE
OPEN
TOP
MULTI-COLOR FLUORESCENT DISPLAY
AS/PS T/F 1
Control Audio
2 SCN 4 3 RPT
POWER LEVEL METER
D.DN 5 RND 6 D.UP
ILL
BAND MODE
Tune
P-950
/Track
/Seek
LOC
MONO
PWR
LOC
LOUD
ST
EQ ROCK
CLAS POP
Sub. W
DISC RND RPT SCAN
TRACK CH CATEGORY/GENRE
CHANNEL LABEL
SONG TITLE
ARTIST
CHANNEL
NUMBER
SFT
0
4
7
1
5
8
2
6
9
3
AUDIO OX
The 80's
The J Rebal Band
I Don't Work Here Anymore
----------------------------------
CH 008 Decades
