© American Audio ® - www.AmericanAudio.us - PSW 15™/PSW 15P™ - Instruction Manual Page 14
Model: American Audio® PSW 15P™ - Professional
Powered Subwoofer
Subwoofer Section:
Dimensions: 13.58” x 16.53” x 26.37” / 344mm x 419mm x 669mm
Weight: 61 Lbs. / 28 kgs
Environmental conditions: Operational temperature: 5 to 35˚C (41 to 95˚F)
Operational humidity: 25 to 85% RH (non-condensation)
Storage temperature: -20 to 60˚C (4 to 140˚F)
Frequency Response: 40KHz - 20KHz (-3dB)
Crossover: 100 - 300HZ Recommended
Power Capacity: 300 Watts RMS - 1000 Watts Peak Power
Amplifier Section:
Power supply: AC 115v/230v, 50/60Hz
Power consumption: 12 Watts Typical
Accessories: I.E.C. Power Cord, 2 Floor Monitor Brackets
Input Sensitivity (Note; Level/Impedance: 0dBV = 1V RMS)
Line:
10K ohms input impedance
70mV RMS Sensitivity for 0dBm Output
Output Sensitivity: 109 dB/m/w
Master Output: 9V RMS Maximum
Frequency Response:
Line:
20Hz-22KHz +/-0.5dB
Microphone: 20Hz-15KHz +/-0.5dB
Signal to Noise Ratio (Maximum Output):
Line:
Better than 94dB
Microphone: Better than 76dB
THD - Total Harmonic Distortion:
Master Output:
Less than 0.1%
NOTES:
The specifications are subject to change to any improvement by negotiations in advance.
The parts are subject to change to any improvement within the range of the specifications.
PSW 15™/PSW 15P™ Technical Specifications
