Setting Mode/Function
Press the MODE button to select the required working mode: Automatic, Cooling, Fan or Heating (Heating is only
available for ALD-12,000EH). The green indicator illustrating your selected mode lights up. It is recommended to
select Cooling or Heating mode and set your desired temperature, as the Auto mode has a preset temperature (please
see below) that cannot be changed.
The indicators of the functions in progress come on at the same time, e.g. Cool and Lo = Cooling mode with Low fan speed.
Auto Mode
When this mode is selected, the unit is preset to the following temperature settings and unit will only start to:
• Cool when room temperature is higher than 75ºF
• Heat when room temperature is lower than 68ºF (ALD-12,000EH only)
If room temperature is between 68ºF and 75ºF, unit will stay in Fan mode. Again, when in Auto Mode, the temperature
settings cannot be changed.
Setting the Temperature in Cooling or Heating Mode
T he display window’s default is to display the ambient room temperature. The green indicator light under RT is on.
(RT = Room Temperature)
To set your desired temperature, press the Temperature up or down buttons (ranging from 62ºF to 90ºF). Each press
will increase or decrease your set temperature by 1ºF. When pressing the temperature up or down buttons, the
window will change to display your set temperature. At this time, the green indicator will light under ST (Set
Temperature). Once the temperature up or down buttons is released, the window will return to displaying the
ambient temperature after a second.
Note: When unit is in the following modes: Auto, Cool, or Heat - the compressor will cool/heat the room to reach
the set temperature. Once the ambient temperature has reached the set temperature, the compressor will stop and
unit will run in Fan mode. To conserve energy, the compressor will not start immediately after a couple degrees
increase or decrease, but will wait for a 5ºF allowance. For example:
In Cooling Mode with a set temperature of 70ºF
When compressor first stops after reaching 70ºF, unit will auto-switch to Fan.
Compressor will start cooling again when ambient temperature increases to 75ºF or above.
In Heating Mode with a set temperature of 72ºF
When compressor first stops after reaching 72ºF, unit will auto-switch to Fan.
Compressor will start heating again when ambient temperature drops to 67ºF or below.
In Auto Mode (with preset temperature of 68ºF for heat and 75ºF for cool)
Compressor will start cooling again when ambient temperature reaches above 80ºF or will start heating when
ambient temperature drops below 63ºF.
Parts
10
11
12
13
14
15
8
44
Control Panel
Not available
on all units Fan Only
Cool
Auto
Set Temp.
Room
Temp.
Low Fan
Not available on all units
High
Fan
High High
Timer
Power
Mode:
AC or Fan
Temp. Up
Temp. Down
Fan Speed:
High / Low
Fan Speed: Fan Speed:
On / Off
Timer
Operation
1. Control Panel
2. Cooling Air Outlet
3. Handle
4. Castors 5. Air Filter
6. Air Inlet
7. Exhaust Air Outlet
8. Cord Hanger
9. Water Stopper (Rubber Plug Inside)
Accessories
10. Adaptor - for insertion over the
hose and into the back of the
air conditioner
11. Exhaust Hose
12. Adjustable Slide Bar
13. Round Connector
14. Cap for Round Connector
15. Remote Control
(Electronic control models only)
33
1
22
Front Back
