17 Direct Spark Ignition (DSI) Burner Assembly
Illus. No. Part No. Qty. Description
1 143226 1 1/2” Brass Street Elbow
2 141317 1 1/2” Bronze Union Elbow
3 882451 1 Ignitor Probe Assembly with High Voltage (HV) Wire
(includes illus. nos. 3 and 16)
4 128927 1 1/2” 24 VAC Redundant (natural gas) Gas Valve
880960 1 1/2” 24 VAC Redundant (liquid propane) Gas Valve
5 140868 1 #31 Burner Orifice (natural gas) ONLY (40K BTU Burners)
140870 1 #34 Burner Orifice (natural gas) ONLY (35K BTU Burners)
140869 1 #49 Burner Orifice (liquid propane [L.P.] gas) ONLY (40 K BTU Burners)
140871 1 #51 Burner Orifice (liquid propane [L.P.] gas) ONLY (35 K BTU Burners)
6 141129 1 Inshot Burner
7 318293 1 Commercial Electric Oven Housing ONLY
818163 1 Direct Spark Ignition (DSI) Gas Train Assembly Complete (natural gas)
(includes illus. nos. 1 through 14)
883610 1 Liquid Propane (L.P.) Conversion Kit (includes orifice) (40 K BTU Burners)
883799 1 Liquid Propane (L.P.) Conversion Kit (includes orifice) (35 K BTU Burners)
8 318345 1 Commercial Gas Oven Mounting Bracket
9 318395 1 Burner Retainer Clip
10 142953 1 3/8” x 1/2” Steel Bushing
11 818177 1 Gas Burner Mounting Bracket
12 318519 1 Gas Valve Support Bracket
13 150300 12 #10-16 x 1/2” Hex Washer TEK Screw
14 142634 1 3/8” x 19” Pipe Nipple
15 128935 1 Direct Spark Ignition (DSI) Module with Three (3) Tries
16 128919 1 High Voltage (HV) Ignition Cable with Cap
17 152013 2 #6-32 Hex Nut
