HP V191 18.5-inch LED Backlit LCD Monitor - Manual (Page 27)

ENWW
21
B. Technical Specifications
All specifications represent the typical specifications provided by HP's component
manufacturers; actual performance may vary either higher or lower.
HP LCD Monitors
Face treatment: Glare polarizer with hard coating
Input terminal:
VGA connector
DVI-D 24-pin D-type connector (select models)
Table B-1 Model V191, LV1911, W1971a, W1972a, W1952a,
LV2011, LV2011q, W2071d, W2072a, W2072b, W2052a, LV2311,W2371d
Specifications: 18.5 (in) 20 (in) 23 (in)
Display Type: TFT LCD active matrix TFT LCD active matrix TFT LCD active matrix
Viewable Image Size 47.0 cm (18.5 in.) diagonal 50.8 cm (20 in.) diagonal 58.42 cm (23 in.) diagonal
Tilt -4 ° (+/-1)~+18° (+/-1) -4 ° (+/-1)~+18° (+/-1) -4 ° (+/-1)~+18° (+/-1)
Maximum Weight (unpacked) 2.7 kg(5.9 lbs) 3.5 kg(7.7 lbs) 3.4 kg(7.5 lbs)
Dimensions (h x w x d) 339.5 mm x446.1 mm
x170.2mm
13.37 x 17.56 x 6.7 in 356.6mm x477.3 mm
x170.2mm
14 x 18.8x6.7 in
(W2071d:358.2mm x
484.5 mm x 170.1mm
14.1 x 19.07 x 6.7 in) 396.2mm x554.5mm
x185.2mm
15.6 x 21.8 x 7.3 in
Maximum Graphics Resolution 1366 x 768 @ 60 Hz 1600 x 900 @ 60 Hz 1920 x 1080 @ 60 Hz
Optimum Graphics Resolution 1366 x 768 @ 60 Hz 1600 x 900 @ 60 Hz 1920 x 1080 @ 60 Hz
Text Mode 720 x 400 720 x 400 720 x 400
Dot Pitch 0.3 x 0.3 mm 0.2768 x 0.2768 mm 0.265 x 0.265 mm
Horizontal Frequency (analog
mode) 24 to 83 kHz 24 to 83 kHz 24 to 94 kHz
Vertical Frequency (analog mode) 50 to 76 Hz 50 to 76 Hz 50 to 76 Hz
Operating Temperature 41 ° to 95°F (5° to 35°C) 41 ° to 95°F (5° to 35°C) 41 ° to 95°F (5° to 35°C)
Non-Operating Temperature 41 ° to 95°F (5° to 35°C) 41 ° to 95°F (5° to 35°C) -4 ° to 140°F (-20° to 60°C)
Operating Humidity 15% to 90% 15% to 90% 15% to 90%
Non-Operating Humidity 5% to 90% 5% to 90% 5% to 90%
Power Source 100-240V~, 50/60 Hz 100-240V~, 50/60 Hz 100-240V~, 50/60 Hz
Power Consumption 26 watts (W) 26 watts (W) 32 watts (W)
Sleep Power Consumption <0.5 watts (W) <0.5 watts (W) <0.5 watts (W)
