REMOTE VEHICLE STARTER/ALARM
INSTALLATION MANUAL
Step 1 - Within 3 seconds turn the ignition ON-OFF-ON-OFF-ON - Leaving
Key ON
Step 2 - Press and hold the Program Button - The park Lights will turn ON
and the siren will chirp once. If the park lights do not come on at
this point, turn the ignition key off for 5 seconds, then repeat step 1.
Step 3 - Continue to hold the Program Button, the park lights will turn off
and the Siren will chirp 5 times quickly.
Step 4 - While holding the Program Button, press the LOCK button on each
of the remote’s to be programmed. If remote’s are being
programmed for 2nd Car Operation press the # button on each of
the 2nd car remote’s to be programmed. The park lights will flash
once and the horn will honk once each time a new code is learned.
Note: Transmitter programming must done quickly. Do not pause more than
one second between each transmitter. All the transmitters to be used must be
programmed at the same time. All transmitters not programmed at this time will
be erased from memory for security. The system holds a maximum of 4
transmitter Codes including 2nd car remote codes.
Carefully remove
the screw from
the back of the
remote.
Remove the top case
Then replace the
battery.
Replace top case.
Re-install screw.
Test remote for
proper operation.
The transmitter battery should be changed at least once every year to maintain
proper operating range. Replace with quality23A 12volt Alkaline battery.
Transmitter Programming
Battery Replacement
Ignition 3x
On/Off
On/Off On
Press and
HOLD the
Program
Button
Press the
Lock Button
Press the
Lock Button
Press the
# Button
Press the
# Button
Single Car Operation,
Program up to 4 remote’s
Dual Car, Control 2 Ultra
Start vehicles with the same
remote
