Smart-UPS 750/1000/1500/2200/3000 VA 120/230 Vac Tower
2
Rear panels
USB port
750 VA 120 Vac
750 VA 230 Vac
Serial port
Ground screw
Smart slot
Circuit breaker
UPS input
Outlets
EPO connector
1000/1500 VA 120 Vac
1000/1500 VA 230 Vac
2200 VA 120 Vac/3000 VA 120 Vac†
2200/3000 VA 230 Vac
†Circuit breaker may be different than shown.
