Page 12
Floor Space
Gas ......................................................... 67” Deep x 47” W x 89-1/8” H
(1702 mm x 1194 mm x 2264 mm)
Steam ...................................................... 67” Deep x 47” W x 93-3/4” H
(1702 mm x 1194 mm x 2382 mm)
Door Opening ............................................ 31-1/4” diameter (794 mm)
Basket Size ................................................ 44” diameter x 42” Deep
(1118 mm x 1067 mm)
Basket Load Capacity ............................... 110 lbs. (50 kg) dryweight
Basket Motor ............................................ 1 hp (.75 kW)
Fan Motor .................................................. 1-1/2 hp (1.12 kW)
Basket RPM
Reversing ................................................ 28 (3.2 reversals per minute)
Non-Reversing ....................................... 34
Exhaust Duct ............................................. 12” diameter (305 mm)
Maximum Air Displacement
Steam ...................................................... 2000 cfm (3400 m
3 /h)
Gas ......................................................... 2000 cfm (3400 m 3 /h))
Recommended Operating Range .............. 1800-2000 cfm
(3060-3400 m
3 /h)
Net Weight (approximate)
Steam ..................................................... 1,614 lb. (733 kg)
Gas ......................................................... 1,515 lb. (688 kg)
Shipping Weight
Steam - 1 crate (approx.) ..................... 1,764 lb. (801 kg)
Gas - 1 crate (approx.) ........................ 1,665 lb. (756 kg)
Export Shipping Dimensions ..................... 93” L x 53” W x 78” H - 232.7 cu. ft.
(2363 mm x 1347 mm x 1982 mm - 6.59 m³
BTU Input Rating ....................................... 250,000 Btu/h (63,000 kcal/h) (nat.,
mixed and mfg. gases) 250,000 Btu/h
(63,000 kcal/h) (propane and butane
gases)
Gas Supply ................................................. 3/4” (DN20) pipe connection
Electric Ignition ........................................ Direct Spark Ignition System
Manifold Gas Pressure ............................. 3.5” w.c. (8.8 mbar) Max. (Nat. Gas);
11” w.c. (27.4 mbar) (LP Gas)
Drying Time (dry weight) ......................... 110 lb. (49.9 kg) (Indian Head)
(Approximate - testing
in laboratory) ........................................ 70% water retention - 25 min.
50% water retention - 22 min.
SPECIFICATIONS
GENERAL
SPECIFICATIONS FOR
110 lb. DRYERS
